Model
|
CATPC024CZ101
|
CAPC038CZ101
|
CAPC055CZ101
|
|
Processor system
|
CPU
|
Six-Core ARM® 64-bit processor
|
|
Frequency
|
2.0 GHz
|
|
SOC
|
Rockchip RK3399 (28nm HKMG Process)
|
|
GPU
|
Technology
|
ARM Mali-T860 MP4 Quad-Core GPU
|
|
Capability
|
Completely compatible with OpenGL ES1.1/2.0/3.0/3.1, OpenCL and DirectX 11.1
|
|
AFBC
|
Support
|
|
Display
|
Screen size
|
24 inch
|
38 inch
|
55 Inch
|
|
Resolution
|
1920(RGB)×360
|
1920(RGB)×560
|
1920(RGB)×317
|
|
Brightness
|
700 cd/m² (Typ.)
|
700 cd/m² (Typ.)
|
600 cd/m² (Typ.)
|
|
Support color
|
16.7M
|
16.7M
|
1.07B
|
|
Contrast
|
1000:1
|
4000:1
|
5000:1
|
|
Viewing angle
|
85/80/88/85 (Min.)(CR≥10)
|
88/88/88/88 (Min.)(CR≥10)
|
89/89/89/89 (Min.)(CR≥10)
|
|
Lamp Type
|
WLED, >30K hours
|
WLED, >30K hours
|
WLED, >30K hours
|
|
Memory
|
Technology
|
Dual-Channel DDR3
|
|
max
|
32GB
|
|
Network
|
Ethernet
|
10/100/1000Mbps Ethernet
|
|
WIFI
|
2.4GHz/5GHz dual band WIFI, supports Wi-Fi 802.11b/g/n/ac
|
|
Bluetooth
|
V2.1+EDR/Bluetooth 3.0/3.0+HS/4.0
|
|
4G
|
LTE-TDD/LTE-FDD/TD-SCDMA/EDGE/GPRS/GSM(optional)
|
|
Audio
|
Connector
|
1 x Analog audio (via 3.5mm Combo Audio Jack for audio input and ouput)
|
|
1 x LINEOUT for audio output
|
|
Display
|
HDMI
|
1 x HDMI 2.0 , Support maximum 4K*2K@60Hz display
|
|
4K/2K
|
1 x V-BY-ONE , Support 4K2K @60Hz
|
|
eDP
|
1 x eDP 1.3 ( 4 lanes with 10.8Gbps )
|
|
Built-in I/O Interface
|
USB
|
6*USB-2.0 HOST , 1*USB3.0 HOST , 1*USB3.0 Type_C
|
|
HDMI
|
1*HDMI IN
|
|
PCIe
|
1*Mini PCIe( 4G LTE) , 1*PCIe_1.27 host
|
|
SIM
|
1*SIM card slot
|
|
Press buttons
|
1*Reset, 1*Power, 1*Upgrade
|
|
Serial connectors
|
4*RS232 , 1*UART TTL
|
|
IO
|
4*IO
|
|
Wigan interface
|
2*Wigan
|
|
Watchdog
|
Type
|
support software watch dog
|
|
Power
|
Power supply voltage
|
100V-240V
|
100V-240V
|
100V-240V
|
|
Power consumption(Typical)
|
30W
|
70W
|
115W
|
|
Power consumption(Stand by.)
|
≦1W
|
≦1W
|
≦1W
|
|
Environment
|
Working temperature(℃)
|
0 ~ +50
|
|
Working humidity(RH)
|
10% - 90%
|
|
Others
|
Operating system
|
Android 7.1 , Ubuntu 16.04 , u-boot
|
