Giant Pcap Touch PCs
CCETOUCH is one of China manufacturer & supplier who mainly produces Giant Pcap Touch PCs with many years of experience. Hope to build business relationship with you. Slim Design Pcap Multi Touch PCs in 32"/55"/65"
Send Inquiry
Product Description
CCETOUCH is one of prominent manufacturer, producer, and exporter of Giant Pcap Touch PCs in China.
Specifications
|
Model |
CTPC032DR102 |
CTPC055DR001 |
CTPC065DR102 |
|
|
Processor system |
CPU |
Integrated Intel® I5-6360U dual core processor, TDP15W |
||
|
Frequency |
2.0 GHz |
|||
|
Chipset |
SOC |
|||
|
Graphics |
Technology |
Integrated Intel® HD Graphics 540 |
||
|
Capability |
1*VGA,1*support dual channel 24bit LVDS,1*HDMI |
|||
|
AFBC |
Support |
|||
|
Display |
Screen size |
32 inch |
55 inch |
65 Inch |
|
Resolution |
1920(RGB)×1080 [FHD] 69PPI |
3840(RGB)×2160 [UHD] 80PPI |
3840(RGB)×2160 [UHD] 68PPI |
|
|
Brightness |
400 cd/m² (Typ.) |
500 cd/m² (Typ.) |
500 cd/m² (Typ.) |
|
|
Support color |
16.7M , 72% NTSC |
1.07B |
1.07B , 68% NTSC |
|
|
Contrast |
1200:1 (Typ.) |
1100:1 |
1100:1 |
|
|
Viewing angle |
89/89/89/89 (Typ.)(CR≥10) |
89/89/89/89 (Min.)(CR≥10) |
89/89/89/89 (Min.)(CR≥10) |
|
|
Lamp Type |
WLED, 30K hours |
WLED, 50K hours |
WLED, 50K hours |
|
|
Touch screen |
Type |
Projected capacitive touch screen |
||
|
Point of touch |
10 point touch screen |
|||
|
Light transmittance |
>93% |
|||
|
Surface Hardness |
7H |
|||
|
Memory |
Technology |
2* DDR3L SODIMM slot |
||
|
max |
32GB |
|||
|
Network |
Ethernet |
2* Intel® 211AT Gigabit Ethernet,support Wake On LAN / PXE |
||
|
WIFI |
Theros AR5BHB116 AR9382 PCI-E 300M wireless card, supports 2.4GHz/5.8GHz |
|||
|
4G |
LTE-TDD/LTE-FDD/TD-SCDMA/EDGE/GPRS/GSM(optional) |
|||
|
Audio |
Chipset |
Integrated ALC662 6-channel high fidelity audio controller |
||
|
Connector |
1*MIC, 1*Line_out |
|||
|
External I/O Interface |
USB |
4(2*USB 3.0, 2*USB 2.0) |
||
|
HDMI |
1*HDMI out |
|||
|
VGA |
1*VGA |
|||
|
Gigabit LAN port |
2*RJ45 |
|||
|
Audio |
1*MIC, 1*Line_out |
|||
|
Serial connectors |
4(3*RS232 , 1*RS485) |
|||
|
WIFI antenna |
2*SMA connectors |
|||
|
Power input |
DC 12V |
|||
|
Switch |
1*motherboard power switch |
|||
|
Built-in I/O |
COM |
2*RS232 |
||
|
USB |
4* USB 2.0 port 2*5pin |
|||
|
SIM socket |
1 |
|||
|
Power connector |
1*4 pin ATX power supply connector, support 12V input output |
|||
|
Watchdog |
Type |
Support hardware reset function(L256, 0~255 seconds) |
||
|
GPIO |
GPIO |
Support 4 ways input output GPIO |
||
|
BIOS |
version |
AMI 64Mb Flash ROM |
||
|
Power |
Power supply voltage |
AC 100V-240V |
AC 100V-240V |
AC 100V-240V |
|
Power consumption(Typical) |
95W |
130W |
180W |
|
|
Environment |
Working temperature(℃) |
0℃~50℃ |
||
|
Working humidity(RH) |
10% - 90% |
|||
|
Others |
Operating system |
Win10; Linux; 32Bit/64Bit |
||
|
Mount |
Frame Mount&VESA 100 |
|||
Ordering lnformation
|
Part Number |
Description |
|
CTPC032DR102-V1 |
32" Rugged Front IP65 Fanless Touch Screen Computer with Integrated Intel® I5-6360U dual core processor, Pcap 10 points touch screen, fanless design, AC 100V-240V power input |
|
CTPC055DR001-V1 |
55" Rugged Front IP65 Fanless Touch Screen Computer with Integrated Intel® I5-6360U dual core processor, Pcap 10 points touch screen, fanless design, AC 100V-240V power input |
|
CTPC065DR102-V1 |
65" Rugged Front IP65 Fanless Touch Screen Computer with Integrated Intel® I5-6360U dual core processor, Pcap 10 points touch screen, fanless design, AC 100V-240V power input |
